The CNC SZGH-540/650 on the basis of SZGH-540 or SZGH-650, a 4-axis rotary table or a 5-axis rotary table can be added to realize the function of completing multi-faceted three-dimensional processing in one clamping.It is widely used in mold making and other functions that require drilling and tapping or three-dimensional carving on multiple surfaces.
configuration parameter:
SZGH540 SZGH-650
product category | Product Parameter | Product Parameter |
Max. milling cutter diameter | Ф60mm | Ф100mm |
Handle Type | BT30 | BT40/BT30 |
Magazine capacity | 6 gangs/8 magazines | 10 gangs/12 magazines |
Repeatability | 0.01mm | 0.01mm |
Surface engraving accuracy | ±0.06mm/±0.01mm | ±0.02mm/±0.01mm |
X-axis effective travel | 400mm | 500mm |
Y-axis effective travel | 500mm | 600mm |
Z-axis effective travel | 200mm | 300mm |
X-axis rapid traverse | 30m/min | 30m/min |
Y-axis rapid traverse | 30m/min | 30m/min |
Z-axis rapid traverse | 25m/min |
The SZGH-540/654 CNC machine is heavy enough to support fast the high-speed and stable movementof the driving head.The CNC machine's total weight is 1900kg/2900kg.Dimensions are 1350mm x 1050mm x 2050mm and 1650mmx1800mmx2450mm.
SZGH-540/650 CNC Machine support typically requires a three-phase power input (380-440V, 50/60Hz) for the main motor and spindle drive.Adopting SZGH electric control package to make electromechanical cooperation play the best efficiency.
